5-17 Operation Command/Frequency Command Sources Monitor
5
5-17 Operation Command/Frequency
Command Sources Monitor
Displays the operation command sources and the frequency command sources that are currently
enabled.
Precautions for Correct Use
Command sources vary according to the state of terminal functions as well as to the settings.
Commands not input from the currently enabled command sources will be ignored.
 Parameter
Item Parameter Data Description
Speed command
destination monitor
(main)
[dC-07]
01 to 07,
09 to 34
00 (disabled), 01 (Ai1), 02 (Ai2), 03 (Ai3),
07 (Multistage speed 0[Ab110]/[Ab210]),
08 (auxiliary speed[AA104]/[AA204]),
09 (Multistage speed 1[Ab-11]),
10 (Multistage speed 2[Ab-12]),
11 (Multistage speed 3[Ab-13]),
12 (Multistage speed 4[Ab-14]),
13 (Multistage speed 5[Ab-15]),
14 (Multistage speed 6[Ab-16]),
15 (Multistage speed 7[Ab-17]),
16 (Multistage speed 8[Ab-18]),
17 (Multistage speed 9[Ab-19]),
18 (Multistage speed 10[Ab-20]),
19 (Multistage speed 11[Ab-21]),
20 (Multistage speed 12[Ab-22]),
21 (Multistage speed 13[Ab-23]),
22 (Multistage speed 14[Ab-24]),
23 (Multistage speed 15[Ab-25]), 24 (JG[AG-20]),
25 (RS485), 29 (Pulse array (inverter)),
30 (Pulse array (Option))
31 (Drive Programming), 32 (PID),
34 (AHD retention speed)
Speed command
destination monitor
(auxiliary)
[dC-08] 00 to 34
Operation command
destination monitor
[dC-10] 00 to 06
00 ([FW]/[RV] terminal)/01 (3 wire)/
02 (RUN key on LCD operator)/
03 (RS485 setting)/04 (Option 1)/
05 (Option 2)/06 (Option 3)
