8-6 Alarm Signal
8
8-6-13 RUN Time Over Signal (RNT)
 Parameter
If the total RUN time or ON time of the inverter exceeds the RUN Time/Power ON Time level (CE-36),
the inverter will output a RUN time over (RNT).
Assign the output terminal function 024 [RNT] RUN time over signal to one of [CC-01] to [CC-07] that
corresponds to the output terminal and output the signal.
Specify the RUN time/power-on time level [CE-36].
Precautions for Correct Use
When specifying the time level as a guideline for replacement, use a number with an adequate
margin.
 Parameter
Item Parameter Data Description
Output terminal func-
tion selection 11-15
[CC-01] to
[CC-05]
030
The cooling fan rotation speed reduction signal
[WAF] is output.
OFF: No warning
ON: Fan rotation speed has decreased
Relay output terminal
function selection
16A-16C
[CC-06]
Relay output terminal
function selection
AL1-AL0/AL2-AL0
[CC-07]
Life diagnostic monitor [dC-16] LL to HH
The monitors become H at the end of the life spans.
The monitor on the right indicates the lives of the
capacitors on the circuit board, whereas that on the
left indicates the life of the cooling fan.
8-6-13 RUN Time Over Signal (RNT)
Item Parameter Data Description
Output terminal func-
tion selection 11-15
[CC-01] to
[CC-05]
024
The RUN time over signal [RNT] is output.
OFF: Less than or equal to the RUN time level
ON: More than the RUN time level
Relay output terminal
function selection
16A-16C
[CC-06]
Relay output terminal
function selection
AL1-AL0/AL2-AL0
[CC-07]
RUN time/power-on
time level
[CE-36] 0 to 100000[hour]
This function does not work when this level has been
set to 0. Specify 1 to 100,000 hours.
Cumulative operating
hours monitor during
RUN
[dC-22] 0 to 100000[hour]
The number of hours when the inverter outputs is
stored for monitoring.
