5 - 11
5 Monitor
High-function General-purpose Inverter RX2 Series User’s Manual
5-5 P-N Voltage Monitor
5
5-5 P-N Voltage Monitor
Displays P-N voltage charged in the main circuit capacitor of an inverter.
Precautions for Correct Use
P-N voltage is DC voltage. The overvoltage error [E007] is generated in the following cases:
• When P-N voltage is over around 405 VDC in the class of 200 V inverter.
• When P-N voltage is over around 810 VDC in the class of 400 V inverter.
 Parameter
Item Parameter Data Description
DC voltage monitor [dA-40] 0.0 to 1000.0 (V) Displays the P-N voltage of inverter.
