5 - 19
5 Monitor
High-function General-purpose Inverter RX2 Series User’s Manual
5-10 Electronic Thermal Load Ratio Monitor
5
5-10-1 Electronic Thermal Load Ratio Monitor of Motor
5-10 Electronic Thermal Load Ratio
Monitor
Display the electric thermal load ratio of the motor. The overload protection error [E005] is generated
when the displayed thermal load ratio is about to exceed 100%.
Precautions for Correct Use
Appropriately perform the basic settings of motor and electric thermal function settings.
 Parameter
The monitor displays electronic thermal load ratio of the inverter. The controller overload protection
error [E039] is generated when the displayed thermal load ratio exceeds 100%.
Precautions for Correct Use
The heat characteristics of the inverter has been predetermined.
 Parameter
5-10-1 Electronic Thermal Load Ratio Monitor of Motor
Item Parameter Data Description
Electronic thermal
duty ratio monitor
MTR
[dA-42] 0.00 to 100.00 (%)
Displays the thermal load ratio of the
motor.
5-10-2 Electronic Thermal Load Ratio Monitor of Inverter
Item Parameter Data Description
Electronic thermal duty
ratio monitor CTL
[dA-43] 0.00 to 100.00 (%)
Displays the thermal load ratio of the
inverter.
