2-3-11 Compatibility Conditions of UL/CSA Standards
The condition in the next section UL standard explain the condition of the electrical safety. It is neces-
sary to comply with the description items such as temperature condition, installation condition etc.
UL CAUTION
GENERAL:
Model 3G3RX2 series inverter is an open type AC Inverter with three phase input and three phase out-
put. It is intended to be used in an enclosure. It is used to provide both an adjustable voltage and
adjustable frequency to the ac motor. The inverter automatically maintains the required volts-Hz ratio
allowing the capability through the motor speed range. It is a multi-rated device and the ratings are
selectable according to load types by operator with key pad operation.
 3G3RX2 Series Models Short Circuit Rating and Overcurrent Protection
Device Rating
•3G3RX2-A2 series models
Suitable for use on a circuit capable of delivering not more than (a) rms symmetrical amperes, at
(b) V maximum. (see table below)
•3G3RX2-A4 3G3RX2-B4 series models
Suitable for use on a circuit capable of delivering not more than (a) rms symmetrical amperes, at
(b) V maximum. (see table below)
Conditions of Electrical Safety (LVD)
2-3-11 Compatibility Conditions of UL/CSA Standards
Standards
US UL61800-5-1
CA CSA 22.2 No.274
FS IEC61800-5-2:2016 STO SIL3
ISO13849-1:2015 Cat.4 PLe
Markings:
Maximum Surrounding Temperature:
ND (Normal Duty): 50°C
LD (Low Duty):
50°C
*1
*1. For actual use, use within the temperature range indicated in the common specifications.
VLD (Very Low Duty):
45°C
*1
Storage Environment rating: 65°C (for transportation)
Instruction for installation: pollution degree 2 environment and Over voltage category III
Electrical Connections: See [Main circuit Wiring Diagram] of this Instruction Manual
Interconnection and wiring diagrams: See [Outline of control circuit] of this Instruction Manual
3G3RX2-
(a) (b)
200V A2004 to A2220 5,000A rms 240V
A2300 to A2550 10,000A rms 240V
400V A4007 to A4220 5,000A rms 500V
A4300 to A4550,B4750, B4900 10,000A rms 500V
B411K, B413K 18,000A rms 500V
