5 - 25
5 Monitor
High-function General-purpose Inverter RX2 Series User’s Manual
5-15 Analog Terminal Setting Monitor
5
5-15 Analog Terminal Setting Monitor
Displays the state of analog input/output changeover switch.
Precautions for Correct Use
• Note that the data cannot be obtained appropriately if the analog input switch selection differs
from the actual input, which results in a damage.
• The data cannot be output appropriately if an analog output switch selection differs from the
actual output.
• If the data on analog switch monitor does not switch after the switch is switched, check the
switch because the switch may not be fully switched or may be damaged.
Parameter
Item Parameter Data Description
Analog I/O selection
monitor
[dA-60]
VVVVVVVV to
AAAAAAAA
Displays whether an analog input/output terminal is a
voltage input/output terminal or a current input/out ter-
minal.
[Left side] (Reserved) (Reserved) (Reserved) (terminal
Ai3 (Ii3/Vi3)) (terminal Ao2) (terminal Ao1) (terminal
Ai2) (terminal Ai1) [Right side]
V: voltage/A: current
To Next Page
