Omron RX2 Series User Manual

6 Basic Parameter Settings
6 - 8
High-function General-purpose Inverter RX2 Series User’s Manual
6-2 Parameter Setting for Motor Related
Basic parameters to control and protect the motor are set.
The following basic parameters need to be set for any control type regardless of controlling method.
The motor operation could be stabilized if the motor items are set to the inverter.
The induction motor (IM) and synchronous motor (SM) / permanent magnet motor (PMM) are set sepa-
rately.
6-2-1 Motor Basic Settings
Induction Motor (IM) Parameter
Items of
Induction motor
Parameters of inverter
Setting range
(unit)
Description Default data
Capacity [Hb102]
Async.Motor
capacity setting,
1st-motor
0.01 to 160.00
(kW)
Sets the motor capacity.
Varies
depending
on inverter
models and
settings of
duty rating.
Number of motor
poles
[Hb103]
Async.Motor poles
setting, 1st-motor
2 to 48 (poles)
Sets the number of motor
poles.
4
Frequency
[Hb104]
Async.Motor Base
frequency setting,
1st-motor
10.00 to 590.00
(Hz)
Sets the base frequency
of motor.
50
*1
*1. Default data when default data selection (UB-02) is set to 01.
[Hb105]
Async.Motor Maxi-
mum frequency
setting, 1st-motor
10.00 to 590.00
(Hz)
Sets the max. frequency
of motor.
50
*1
Voltage [Hb106]
Async.Motor rated
voltage, 1st-motor
1 to 1000 (V)
Sets the rated voltage of
motor.
200 V: 230
*1
400 V: 400
*1
Current [Hb108]
Async.Motor rated
current, 1st-motor
0.01 to 10000.00
(A)
Sets the rated current of
motor.
Varies
depending
on inverter
models and
settings of
duty rating.
