6 Basic Parameter Settings
High-function General-purpose Inverter RX2 Series User’s Manual
6-1 Basic Parameter Settings
6
6-1-2 Inverter Initialization
Table of Initialization Targets
[Ub-01] Selection of initialization:
Initialization targets are indicated by .
Initialize Data selection [Ub-02]
The data is initialized in the following manners, depending on the selected mode. The default data is
common in other parameters.
Set the default data during shipment to 01 (Mode 1).
[Ub-01]
(1)
History data
(2)
Setting of I/O
terminal
(3)
Communica-
tion function
(4)
Other than
parameters (2)
and (3)
(5)
DriveProgram-
ming
00
01
02
03
04
05
06
07
08
Code Function Name Mode 0
Mode 1
(Default data
during shipment)
Mode 2 Mode 3
AA101 Main speed input source
selection, 1st-motor
07 (Parameter set-
ting)
01 (Ai1 terminal
input)
01 (Ai1 terminal
input)
01 (Ai1 terminal
input)
AA111 Run-command input source
selection, 1st-motor
02 (RUN key on
operator LCD
Operator)
00 ([FW]/[RV] ter-
minal)
00 ([FW]/[RV] ter-
minal)
00 ([FW]/[RV] ter-
minal)
AA201 Main speed input source
selection, 2nd-motor
07 (Parameter set-
ting)
01 (Ai1 terminal
input)
01 (Ai1 terminal
input)
01 (Ai1 terminal
input)
AA211 Run-command input source
selection, 2nd-motor
02 (RUN key on
operator LCD
Operator)
00 ([FW]/[RV] ter-
minal)
00 ([FW]/[RV] ter-
minal)
00 ([FW]/[RV] ter-
minal)
bC111 Electronic thermal charac-
teristic selection, 1st-motor
00 (Reduction
characteristics)
01 (Constant
torque characteris-
tics)
01 (Constant
torque characteris-
tics)
01 (Constant
torque characteris-
tics)
bC211 Electronic thermal charac-
teristic selection, 2nd-motor
00 (Reduction
characteristics)
01 (Constant
torque characteris-
tics)
01 (Constant
torque characteris-
tics)
01 (Constant
torque characteris-
tics)
Hb104 Async.Motor Base fre-
quency setting, 1st-motor
60.00 50.00 60.00 50.00
Hb105 Async.Motor Maximum fre-
quency setting, 1st-motor
60.00 50.00 60.00 50.00
Hb106 Async.Motor rated voltage,
1st-motor
200 V class: 200
400 V class: 400
200 V class: 230
400 V class: 400
200 V class: 230
400 V class: 460
200 V class: 230
400 V class: 400
Hb204 Async.Motor Base fre-
quency setting, 2nd-motor
60.00 50.00 60.00 50.00
Hb205 Async.Motor Maximum fre-
quency setting, 2nd-motor
60.00 50.00 60.00 50.00
Hb206 Async.Motor rated voltage,
2nd-motor
200 V class: 200
400 V class: 400
200 V class: 230
400 V class: 400
200 V class: 230
400 V class: 460
200 V class: 230
400 V class: 400
