Appendices B STO Function

B - 4

High-function General-purpose Inverter RX2 Series User’s Manual

B-1-8 Safety Related Parameter

Parameter Data Criteria

PL e

EN ISO 13849-1:2015

CAT. 4

MTTFd 100 years

DCavg 99.8%

SIL 3

IEC61508: 2010

IEC61800-5-2:2016

EN61800-5-2:2007

IEC/EN62061:2012

HFT 1

SFF 99.9%

PFH

1.18 × 10

-9

PFD

1.03 × 10

-4
