2 Design
2 - 80
High-function General-purpose Inverter RX2 Series User’s Manual
 400V class
Guide for Users
This equipment has been evaluated for conformity in a commercial environment.
When used in a residential environment, it may cause radio interference.
The following describes outlines of option and peripheral devices and reference manual.
When you desire to reduce the motor’s deceleration time, use this unit in combination with braking
resistor
Model
3G3RX2
Fuse Circuit Breaker
Type
Maximum Rating Maximum Rating
Voltage (V) Current (A) Voltage (V) Current (A)
A4007 Class J or T 600 15 - -
A4015 Class J or T 600 20 - -
A4022 Class J or T 600 30 - -
A4037 Class J or T 600 30 - -
A4055 Class J or T 600 75 - -
A4075 Class J or T 600 75 - -
A4110 Class J or T 600 75 - -
A4150 Class J or T 600 100 - -
A4185 Class J or T 600 100 - -
A4220 Class J or T 600 100 - -
A4300 Class J or T 600 200 - -
A4370 Class J or T 600 200 - -
A4450 Class J or T 600 200 - -
A4550 Class J or T 600 250 - -
B4750 Class J or T 600 300 - -
B4900 Class J or T 600 400 - -
B411K Class J or T 600 500 - -
B413K Class J or T 600 500 - -
2-3-12 Korean Radio Regulation (KC)
2-3-13 Reference Manual for Options
Regenerating Braking Unit (3G3AX-RBU )
Name Instruction Manual number
Regenerative Braking Unit 3G3AX-RBU  User’s Manual I563-E1
یࡈ࢕߇ΰח
ࢇЕ߶הࡈ୚ˁ߾۰یࡈଟּࢶࡳԻࢶଢ۽ૡɼձ؇ࡵԻ۰
ɼࢽࡈ୚ˁ߾۰یࡈଜЕˁࡉࢷળɾۺࢂࡉԮɼ࢑ݡТЬ
