Omron RX2 Series User Manual

8 - 173
8 Applied Settings
High-function General-purpose Inverter RX2 Series User’s Manual
8-11 Output Terminal Function
8
8-11-1 Overview
8-11 Output Terminal Function
Output terminals 11 to 15 are used for open collector output, and Relay output terminals 16 and 17 are
used for relay output. Relay output 16 serves as a contact a relay, and Relay output 17 serves as a con-
tact c relay.
For the content of an output signal, by allocating the functions that you want to output to [CC-01] to
[CC-07], you will be able to allow the corresponding output terminal contacts to operate.
You can switch an output signal level with the Contacts a/b selection functions of [CC-11] to [CC-17].
Precautions for Correct Use
To use the contact c relay, please check the control circuit power supply and the relay output
terminals whether they are turned on or off.
 Parameter
 Terminals Corresponding to Parameters
8-11-1 Overview
Item Parameter Data Description
Output terminal func-
tion selection
[CC-01] to
[CC-05]
Next item: Table
of output terminal
selections
Outputs the allocated function to the corresponding
output terminal.
Relay output terminal
function selection
[CC-06]
Relay output terminal
function selection
[CC-07]
Output terminal func-
tion selection
[CC-11] to
[CC-15]
00 Operates as Contact a (NO).
Relay output terminal
function selection a/b
(NO/NC) selection
[CC-16]
01 Operates as Contact b (NC).
Relay output terminal
function selection a/b
(NO/NC) selection
[CC-17]
16A
16C
1112131415
CM2
AL2
AL1
AL0
[CC-07]
[CC-06]
[CC-05]
[CC-04]
[CC-03]
[CC-02]
[CC-01]
Output terminals
Relay
output terminals
Alarm relay
output terminals
