3 - 55
3 Operation
High-function General-purpose Inverter RX2 Series User’s Manual
3-13 Connection and Functions of CX-Drive
3
3-13-1 CX-Drive Connection Method
3-13 Connection and Functions of
CX-Drive
The inverter/Servo support tool CX-Drive is support software to edit the inverter parameter settings.
Installing the OMRON CX-One software on your PC also installs the CX-Drive simultaneously.
The 3G3RX2 Series Inverter is supported in the following or higher versions of the CX-Drive product:
• CX-One: Ver. 4 or later
• CX-Drive: Ver. 3.0
This section describes how to connect the CX-Drive to an inverter and provides an overview of its func-
tions.
For details on the functions of the CX-Drive, refer to the CX-Drive Operation Manual (Cat. No.
W453-E1).
The following figure shows how to connect the 3G3RX2 Series with the inverter/Servo support tool
CX-Drive.
Connect the CX-Drive directly to the serial communications port of the inverter.
3-13-1 CX-Drive Connection Method
Direct Connection via Serial Communications
To Next Page
