5-14 Analog Input Value Monitor
Displays the input values for Ai1, Ai2 and Ai3 that are currently input to the terminal block of the
inverter.
 Parameter
Item Parameter Data Description
Analog input [Ai1] monitor [dA-61] 0.00 to 100.00 (%) Monitors analog input values.
[Ai1][Ai2]: 0 to 10V/0 to 20mA
[Ai3]: Equivalent to -10 to 10V
Analog input [Ai2] monitor [dA-62] 0.00 to 100.00 (%)
Analog input [Ai3] monitor [dA-63] -100.00 to 100.00 (%)
