3 Operation
3 - 44
High-function General-purpose Inverter RX2 Series User’s Manual
(x) DriveProgramming
Display condition: UE – 02 ≠ 00
Parameters set to the user setting functions [UA-31] to [UA-62], main speed command [FA-01], output
frequency monitor [dA-01], and display selection [UA-10] are displayed.
• Only parameters that have been changed from the factory default settings are displayed.
• All monitor displays [d****] and [F****], display selection [UA-10], and the password for display
[UA-01] are always shown.
Precautions for Correct Use
• The initial value used for comparison is determined by the inverter model and the following
settings.
Initialize Data selection [Ub-02]
Load type selection [Ub-03]
• If you changes the base frequency, the value of the motor constant IO is changed, so the
data-comparison displays the changes in parameter.
All monitor displays [d****] and [F****] and display selection [UA-10] are shown.
Changed parameters can be saved.
When selection of user parameter automatic setting [UA-30] is set to 01, parameters whose data has
been changed are automatically saved in [UA-31] to [UA-62].
Also, when you desire to retrieve history of parameter changes, set selection of user parameter auto-
matic setting [UA-30] to 01.
Up to 32 changed parameters can be saved.
Parameter Name
db-01 Program download monitor
db-02 Program number monitor
db-03 to db-07 Program counter (Task1-5)
db-08 to db-16 User monitor 0-4
db-18 to db-23 Analog output monitor YA0-YA5
UE-01 DriveProgramming execution interval
UE-10 to UE-73 Driveprogramming user parameter U (00)-U(63)
UF-02 to UF-33 DriveProgramming user parameter UL(00)-U(15)
User Setting: [UA-10]=02
Data-comparison Display: [UA-10]=03
Monitor Display: [UA-10]=04
3-8-3 Saving Automatically Changed Parameters
