9 Communications Functions
9 - 40
High-function General-purpose Inverter RX2 Series User’s Manual
Precautions for Correct UsePrecautions for Correct Use
• The “Register No.” in the table header shows the register number used inside the inverter.
• The “Modbus register spec. No.” in the table header shows the register number used to actu-
ally specify the register in the Modbus communication process.
This register number is 1 less than the inverter “Register No.” according to the Modbus com-
munication specifications.
9-5-3 Group F Register List
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
2AF9h 2AF8h
Main Speed reference moni-
tor
FA-01 R/W 0 to 59000 0.01Hz
2AFAh 2AF9h
Sub Speed reference monitor
FA-02
(HIGH)
R/W
-59000 to +59000 (monitor)
0 to 59000 (setting)
0.01(Hz)
2AFBh 2AFAh
FA-03
(LOW)
R/W
2B02h 2B01h
Acceleration time monitor
FA-10
(HIGH)
R/W
0 to 360000 0.01(s)
2B03h 2B02h
FA-11
(LOW)
R/W
2B04h 2B03h
Deceleration time monitor
FA-12
(HIGH)
R/W
0 to 360000 0.01(s)
2B05h 2B04h
FA-13
(LOW)
R/W
2B07h 2B06h Torque reference monitor FA-15 R/W -5000 to 5000 0.1(%)
2B08h 2B07h Torque bias monitor FA-16 R/W -5000 to 5000 0.1(%)
2B0Ch 2B0Bh
Position reference monitor
FA-20
(HIGH)
R/W
-268435455 to 268435455
In high resolution mode:
-1073741823 to 1073741823
1
2B0Dh 2B0Ch
FA-21
(LOW)
R/W
2B16h 2B15h
PID1 Set Value 1 monitor
FA-30
(HIGH)
R/W
0 to 10000
*1
Unit differs
depending
on setting
[AH-03]
[AH-06].
2B17h 2B16h
FA-31
(LOW)
R/W
2B18h 2B17h
PID1 Set Value 2 monitor
FA-32
(HIGH)
R/W
0 to 10000
*1
Unit differs
depending
on setting
[AH-03]
[AH-06].
2B19h 2B18h
FA-33
(LOW)
R/W
2B1Ah 2B19h
PID1 Set Value 3 monitor
FA-34
(HIGH)
R/W
0 to 10000
*1
Unit differs
depending
on setting
[AH-03]
[AH-06].
2B1Bh 2B1Ah
FA-35
(LOW)
R/W
2B1Ch 2B1Bh
PID2 Set Value monitor
FA-36
(HIGH)
R/W
0 to 10000
*2
Unit differs
depending
on setting
[AJ-03]
[AJ-06].
2B1Dh 2B1Ch
FA-37
(LOW)
R/W
