4 - 3
4 Test Run
High-function General-purpose Inverter RX2 Series User’s Manual
4-2 Settings and Commands Required for Running the Inverter
4
4-2 Settings and Commands Required
for Running the Inverter
To turn the motor, configure the following settings.
Precautions for Correct Use
This article explains the settings for operation. Carefully read Safety Instructions before han-
dling the inverter.
1 Basic setting for motor
Set the following parameters in accordance with the plate of motor. Set the data indicating the
basic characteristics of motor.
Note See 6-2-1 Motor Basic Settings on page 6-8 for details.
2 Setting for protection of motor
The motor may be burned if a large current keeps on flowing in the motor; the setting therefore
must be performed appropriately.
Note See 6-6 Thermal Protection of Motor (Electronic Thermal) on page 6-48 for details.
3 Setting for activating the motor
The voltage output of the inverter requires not only an operation command but also a frequency
command. In the initial state, a main speed command is used as a frequency command.
Note For details, see 6-3 Operation Command Settings on page 6-19 and 6-4 Frequency Command Settings on
page 6-25.
Item
Parameter
IM SM(PMM)
Async.Motor capacity setting, 1st-motor [Hb102] [Hd102]
Async.Motor poles setting, 1st-motor [Hb103] [Hd103]
Async.Motor Base frequency setting, 1st-motor [Hb104] [Hd104]
Async.Motor Maximum frequency setting,
1st-motor
[Hb105] [Hd105]
Async.Motor rated voltage, 1st-motor [Hb106] [Hd106]
Async.Motor rated current, 1st-motor [Hb108] [Hd108]
Item Parameter
Electronic thermal level setting, 1st-motor [bC110]
Electronic thermal characteristic selection, 1st-motor [bC111]
Item Parameter
Main speed input source selection, 1st-motor [AA101]
Run-command input source selection, 1st-motor [AA111]
Main Speed reference monitor [FA-01]
To Next Page
