6 Basic Parameter Settings
6 - 24
High-function General-purpose Inverter RX2 Series User’s Manual
The operation command destination can be temporally changed with [F-OP] terminal.
When 023 [F-OP] terminal is ON, the command destination of [CA-71] is employed in a priority to the
operation command destination given in [AA111].
Precautions for Correct Use
• When 023 [F-OP] terminal is ON, the frequency command destination also employs the fre-
quency command selection designated in [CA-70].
• If [AA111] and [CA-71] are set differently from each other, the operation is interrupted when
the [F-OP] terminal is made ON or OFF. The selected operation command is enabled when it
is made OFF and then ON.
Parameter
6-3-8 Temporary Change of Operation Command Destination
Item
Parameters
Data Description
Default
data
Input terminal function
selection
[CA-01] to
[CA-11]
023 [F-OP]: Gives a forced command. -
Speed reference
source selection at
[F-OP] is active
[CA-70] 01 to 15
01: Ai1-L input, 02: Ai2-L input, 03: Ai3-L input,
04: (Reserved), 05: (Reserved), 06: (Reserved),
07: parameter setting,
08: RS485 communication, 09:option 1,
10: option 2, 11: option 3,
12: pulse string input (main body),
13: pulse string input (optional)
14: program function, 15: PID arithmetic
01
RUN command source
selection at [F-OP] is
active
[CA-71] 00 to 06
00: [FW]/[RV] terminal, 01: 3 wire,
02: RUN key on LCD operator,
03: RS485 communication, 04: option 1,
05: option 2, 06: option 3
00
