5 Monitor
High-function General-purpose Inverter RX2 Series User’s Manual
5-12 Braking Resistor Load Ratio Monitor
5
5-12 Braking Resistor Load Ratio Monitor
Display the use rate of braking resistor circuit (BRD).
Precautions for Correct Use
• A setting is required for a braking resistor circuit (BRD) to operate.
For details, see 8-2-5 Regenerative Braking Function on page 8-50.
• The breaking resistor overload error [E006] is generated when the displayed rate exceeds
the Dynamic brake usage rate [bA-60].
 Parameter
Item Parameter Data Description
BRD load factor monitor [dA-41] 0.00 to 100.00 (%)
Displays the load ratio of braking resis-
tor.
Dynamic brake usage rate [bA-60] 0.0 to 100.0 (%)
Sets the maximum use rate of braking
resistor.
