5 Monitor
5 - 20
High-function General-purpose Inverter RX2 Series User’s Manual
5-11 Inverter Rated Monitor
Displays the load rating of the inverter.
Precautions for Correct Use
You should also check the rated current and current derating characteristics because they vary
depending on load type selections.
 Parameter
Displays the rated current of the inverter.
Precautions for Correct Use
You should also check the rated current and current derating characteristics because they vary
depending on load type selections.
 Parameter
5-11-1 Load Rated Monitor
Item Parameter Data Description
Inverter load type selection
monitor
[dC-01]
00 VLD: Very low duty
01 LD: Low duty
02 ND: Normal duty
5-11-2 Rated Current Monitor
Item Parameter Data Description
Rated current monitor [dC-02] 0.0 to 6553.5 [A]
Displays the rated current adopted to the
inverter.
