Omron RX2 Series User Manual

8 - 155
8 Applied Settings
High-function General-purpose Inverter RX2 Series User’s Manual
8-10 Input Terminal Function
8
8-10-1 Overview
 Input Terminal Selections
Function No. Abbreviation Function name Page
000 no Without allocation -
001 FW Normal rotation P. 6-20
002 RV Reverse rotation P. 6-20
003 CF1 Multistage speed 1 P. 6-38
004 CF2 Multistage speed 2 P. 6-38
005 CF3 Multistage speed 3 P. 6-38
006 CF4 Multistage speed 4 P. 6-38
007 SF1 Multistage speed bit 1 P. 6-39
008 SF2 Multistage speed bit 2 P. 6-39
009 SF3 Multistage speed bit 3 P. 6-39
010 SF4 Multistage speed bit 4 P. 6-39
011 SF5 Multistage speed bit 5 P. 6-39
012 SF6 Multistage speed bit 6 P. 6-39
013 SF7 Multistage speed bit 7 P. 6-39
014 ADD Addition of frequency P. 6-41
015 SCHG Switching of instruction P. 6-35
016 STA 3-wire starting up P. 6-21
017 STP 3-wire stopping P. 6-21
018 F/R 3-wire normal and reverse P. 6-21
019 AHD Retention of analog instruction P. 6-42
020 FUP Acceleration through remote operation P. 6-41
021 FDN Deceleration through remote operation P. 6-41
022 UDC Clearing of remote operation data P. 6-41
023 F-OP Forced switching of instruction P. 6-43
024 SET Second control P. 8-80
028 RS Reset P. 8-159
029 JG Jogging P. 8-83
030 DB Braking with external direct current P. 7-83
031 2CH 2-step acceleration/deceleration P. 6-58
032 FRS Stopping of free running P. 7-82
033 EXT External abnormality P. 8-70
034 USP Prevention of power restoration restarting P. 8-71
035 CS Commercial switch P. 8-81
036 SFT Soft-lock P. 3-33
037 BOK Brake check P. 8-85
038 OLR Switching of overload limit P. 8-40
039 KHC Clearing of integrated input power P. 5-15
040 OKHC Clearing of integrated output power P. 5-16
041 PID PID1 invalidation P. 8-18
042 PIDC Resetting of PID1 integration P. 8-17
043 PID2 PID2 invalidation P. 8-33
044 PIDC2 Resetting of PID2 integration P. 8-33
045 PID3 PID3 invalidation P. 8-33
046 PIDC3 Resetting of PID3 integration P. 8-33
047 PID4 PID4 invalidation P. 8-33
048 PIDC4 Resetting of PID4 integration P. 8-33
051 SVC1 PID1 multistage target value 1 P. 8-12
052 SVC2 PID1 multistage target value 2 P. 8-12
053 SVC3 PID1 multistage target value 3 P. 8-12
054 SVC4 PID1 multistage target value 4 P. 8-12
055 PRO Switching of PID gain P. 8-18
056 PIO1 Switching of PID output P. 8-26
