8 Applied Settings
8 - 80
High-function General-purpose Inverter RX2 Series User’s Manual
8-4 Control Function
This function changes the valid parameters by assigning 024[SET] to the input terminal function and
turning it on. In conjunction with [SET], the output terminal 012[SETM] is turned on.
The following is the notation for the parameters that are changed with the [SET] terminal.
Precautions for Correct Use
• The [SET] terminal can be switched while the output of the inverter is blocked. If it is being
switched during the output, it is switched after the output blockage.
• Even if you want to switch the [SET] terminal for immediate operation, take more than 1 sec-
ond for the switching time.
• Example of the Common Settings
• Example of the First Setting
• Example of the Second Setting
8-4-1 2nd Control (SET)
A
b - 01
In-Group Number
SET Function Type
Parameter Group
AA 1 01
In-Group Number
SET Function Type
Parameter Group
AA 2 01
In-Group Number
SET Function Type
Parameter Group
