Appendices A Technical Information

A - 10

High-function General-purpose Inverter RX2 Series User’s Manual

A-2 Parameter Comparison

In some cases, contents about parameters are different between 3G3RX-series V1 and

3G3RX2-series. After checking the descriptions about functions, set the parameters.

3G3RX-series V1 3G3RX2-series

Remarks

Display

code

Function name New code

d001 Output frequency monitor dA-01

d002 Output current monitor dA-02

d003 Operation direction monitor dA-03

d004 PID feedback monitor db-30

d005 Intelligent input monitor dA-51

d006 Intelligent output monitor dA-54

d007 Frequency conversion monitor dA-06

d008 Real frequency monitor dA-08

d009 Torque command monitor FA-15

d010 Torque bias monitor FA-16

d012 Output torque monitor dA-17

d013 Output voltage monitor dA-18

d014 Input power monitor dA-30

d015 Integrated power monitor dA-32

d016

Cumulative operating hours monitor during

RUN

dC-22

d017 Cumulative power-on time dC-24

d018 Cooling fin temperature monitor dC-15

d019 Motor temperature monitor dA-38

d022 Life diagnostic monitor dC-16

d023 Program counter db-03

d024 Program number monitor db-02

d025 User monitor 0 db-08

d026 User monitor 1 db-10

d027 User monitor 2 db-12

d028 Pulse counter monitor dA-28

d029 Position command monitor FA-20

d030 Current position monitor dA-20

d060 Inverter mode monitor

dC-01

dC-45

The monitor can be checked with

dC-01: duty type and dC-45: IM/SM.

d080 Trip frequency monitor
