5 Monitor
5 - 10
High-function General-purpose Inverter RX2 Series User’s Manual
Displays the output current flowing in the motor.
Precautions for Correct Use
The lower the carrier frequency, the more the value of current of monitor may fluctuate,
depending on the PWM output system of the inverter.
 Parameter
Displays the output voltage which is output to the motor.
Precautions for Correct Use
A correct value may not be displayed when the input voltage is low.
 Parameter
5-4-3 Output Current Monitor
Item Parameter Data Description
Output current moni-
tor
[dA-02] 0.00 to 655.35 (A)
Displays the effective value of output
current flowing in the motor.
5-4-4 Output Voltage Monitor
Item Parameter Data Description
Output voltage
monitor
[dA-18] 0.0 to 800.0 (V)
Displays the voltage which is output to the
motor.
