1 - 11
1 Overview
High-function General-purpose Inverter RX2 Series User’s Manual
1-3 Specifications
1
1-3-2 200V Class Specifications
*1. The rated input currents shown in the table are the values when the rated current is output. The values vary depending on impedance on the power supply
(wiring, breaker, input reactor option, etc.)
*2. The power supply equipment capacities shown in the table are the values when 220V rated current is output. The values vary depending on impedance on
the power supply (wiring, breaker, input reactor option, etc.)
*3. The setting of rated values for carrier frequencies [bb101]/[bb201] are internally limited in accordance with the description. Also, it is recommended to set
values equivalent to or above (maximum output frequency for driving ×10) Hz for the setting of carrier frequencies [bb101]/[bb201]. Also, in the case of
induction motor (IM) control, for items other than those subject to V/f control, it is recommended to set carrier frequency at 2kHz or more. In the case of
synchronous motor (SM)/permanent magnet motor (PMM) control, it is recommended to set carrier frequency at 8kHz or more.
*4. The value of the sensor-less vector control applied to the ND rating in the Standard motor. Torque characteristics may vary depending on the control
method and the motor used.
*5. Based on self declaration.
1-3-2 200V Class Specifications
3G3RX2-A2 A2004 A2007 A2015 A2022 A2037 A2055 A2075 A2110 A2150 A2185 A2220 A2300 A2370 A2450 A2550
Applicable motor
(4-pole) capacity (kW)
VLD 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
LD 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
ND 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55
Output
Rated output
current (A)
VLD 4.4 8.0 10.4 15.6 22.8 33.0 46.0 60.0 80.0 93.0 124 153 185 229 295
LD 3.7 6.3 9.4 12.0 19.6 30.0 40.0 56.0 73.0 85.0 113 140 169 210 270
ND 3.2 5.0 8.0 11.0 17.5 25.0 32.0 46.0 64.0 76.0 95.0 122 146 182 220
Overload
current rating
VLD 110% 60sec / 120% 3sec
LD 120% 60sec / 150% 3sec
ND 150% 60sec / 200% 3sec
Rated output voltage 3-phase (3-wire) 200 to 240V (depending on receiving voltage)
Rated
capacity
(kVA)
200V
VLD 1.5 2.8 3.6 5.4 7.9 11.4 15.9 20.8 27.7 32.2 43.0 53.0 64.1 79.3 102.2
LD 1.3 2.2 3.3 4.2 6.8 10.4 13.9 19.4 25.3 29.4 39.1 48.5 58.5 72.7 93.5
ND 1.1 1.7 2.8 3.8 6.1 8.7 11.1 15.9 22.2 26.3 32.9 42.3 50.6 63.0 76.2
240V
VLD 1.8 3.3 4.3 6.5 9.5 13.7 19.1 24.9 33.3 38.7 51.5 63.6 76.9 95.2 122.6
LD 1.5 2.6 3.9 5.0 8.1 12.5 16.6 23.3 30.3 35.3 47.0 58.2 70.3 87.3 112.2
ND 1.3 2.1 3.3 4.6 7.3 10.4 13.3 19.1 26.6 31.6 39.5 50.7 60.7 75.7 91.5
Input
Rated input
current (A) *1
VLD 5.2 9.5 12.4 18.6 27.1 39.3 54.8 71.4 95.2 110.7 147.6 182.1 220.2 272.6 351.2
LD 4.4 7.5 11.2 14.3 23.3 35.7 47.6 66.7 86.9 101.2 134.5 166.7 201.2 250.0 321.4
ND 3.8 6.0 9.5 13.1 20.8 29.8 38.1 54.8 76.2 90.5 113.1 145.2 173.8 216.7 261.9
Rated input AC
voltage
Control power supply: Power supply single phase 200 to 240V/allowable variation range 170 to 264V,
50Hz (allowable variation range: 47.5 to 52.5Hz)/60Hz (allowable variation range: 57 to 63Hz)
Main circuit power supply: 3-phase (3-wire) 200 to 240V/allowable variation range 170 to 264V,
50Hz (allowable variation range: 47.5 to 52.5Hz)/60Hz (allowable variation range: 57 to 63Hz)
Power supply
equipment
capacity (kVA)
*2
VLD 2.0 3.6 4.7 7.1 10.3 15.0 20.9 27.2 36.3 42.2 56.3 69.4 83.9 103.9 133.8
LD 1.7 2.9 4.3 5.4 8.9 13.6 18.1 25.4 33.1 38.6 51.3 63.5 76.7 95.3 122.5
ND 1.5 2.3 3.6 5.0 7.9 11.3 14.5 20.9 29.0 34.5 43.1 55.3 66.2 82.6 99.8
Carrier frequency
operating range *3
VLD 0.5 to 10.0kHz
LD 0.5 to 12.0kHz
ND 0.5 to 16.0kHz
Motor start torque *4 200%/0.3Hz
Braking
Regenerative braking Equipped with BRD circuit (with a discharging resistor separately installed)
Regenerative braking unit
separately installed
Minimum resistance
that can be
connected (Ω)
50 50 35 35 35 16 10 10 7.5 7.5 5 --- --- --- ---
Dimension
Height (mm) 255 255 255 255 255 260 260 260 390 390 390 540 550 550 700
Width (mm) 150 150 150 150 150 210 210 210 245 245 245 300 390 390 480
Depth (mm) 140 140 140 140 140 170 170 170 190 190 190 195 250 250 250
Protective construction IP20*5 / UL open type
Approximate mass (kg) 3333366610101022333347
