Omron RX2 Series User Manual

Appendices C Table of Parameters
C - 4
High-function General-purpose Inverter RX2 Series User’s Manual
C-2 Monitor List
Monitors Related to Output
Code Name Data range
dA-01 Output frequency monitor 0.00 to 590.00 (Hz)
dA-02 Output current monitor 0.0 to 655.35 (A)
dA-03 Operation direction monitor
F (Normal rotation in process)/
r (Reverse rotation in process)/
d (0Hz output)/ o (Stopped)
dA-04
Frequency command after calcula-
tion
-590.00 to 590.00 (Hz)
dA-06
Output frequency conversion moni-
tor
0.00 to 59000.00 (Hz)
dA-08 Speed detection value monitor -590.00 to 590.00 (Hz)
dA-12 Output frequency monitor (with sign) -590.00 to 590.00 (Hz)
dA-14 Frequency upper limit monitor 0.00 to 590.00 (Hz)
dA-15
Torque command monitor after cal-
culation
-1000.0 to 1000.0 (%)
dA-16 Torque limit monitor 0.0 to 500.0 (%)
dA-17 Output torque monitor -1000.0 to 1000.0 (%)
dA-18 Output voltage monitor 0.0 to 800.0 (V)
dA-20 Current position monitor
In the case of AA121=10 and AA123=03, data range
-2147483648 to 2147483647 (pls)
In the case of the condition mentioned above, data range
-536870912 to 536870911 (pls)
dA-26
Pulse train position deviation moni-
tor
-2147483647 to +2147483647 (pls)
dA-28 Pulse counter monitor 0 to 2147483647 (pls)
dA-30 Input power monitor 0.00 to 600.00 (kW)
dA-32 Integrated input power monitor 0.0 to 1000000.0 (kW)
dA-34 Output power monitor 0.00 to 600.00 (kW)
dA-36 Integrated output power monitor 0.0 to 1000000.0 (kW)
dA-38 Motor temperature monitor -20.0 to 200.0 (°C)
dA-40 DC voltage monitor 0.0 to 1000.0 (V)
dA-41 BRD load factor monitor 0.00 to 100.00 (%)
dA-42
Electronic thermal duty ratio moni-
tor (motor)
0.00 to 100.00 (%)
dA-43
Electronic thermal duty ratio moni-
tor (controller (inverter))
0.00 to 100.00 (%)
