9 Communications Functions
9 - 72
High-function General-purpose Inverter RX2 Series User’s Manual
Precautions for Correct UsePrecautions for Correct Use
• The “Register No.” in the table header shows the register number used inside the inverter.
• The “Modbus register spec. No.” in the table header shows the register number used to actu-
ally specify the register in the Modbus communication process.
This register number is 1 less than the inverter “Register No.” according to the Modbus com-
munication specifications.
9-5-6 Group C Register List
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data
Resolution
36B1h 36B0h Input terminal [1] function CA-01 R/W
See <List of input terminal func-
tions> on page C-44.
-
36B2h 36B1h Input terminal [2] function CA-02 R/W
36B3h 36B2h Input terminal [3] function CA-03 R/W
36B4h 36B3h Input terminal [4] function CA-04 R/W
36B5h 36B4h Input terminal [5] function CA-05 R/W
36B6h 36B5h Input terminal [6] function CA-06 R/W
36B7h 36B6h Input terminal [7] function CA-07 R/W
36B8h 36B7h Input terminal [8] function CA-08 R/W
36B9h 36B8h Input terminal [9] function CA-09 R/W
36Bah 36B9h Input terminal [A] function CA-10 R/W
36BBh 36BAh Input terminal [B] function CA-11 R/W
36C5h 36C4h Input terminal [1] active state CA-21 R/W
00: Normally open: NO
01: Normally closed: NC
-
36C6h 36C5h Input terminal [2] active state CA-22 R/W
36C7h 36C6h Input terminal [3] active state CA-23 R/W
36C8h 36C7h Input terminal [4] active state CA-24 R/W
36C9h 36C8h Input terminal [5] active state CA-25 R/W
36Cah 36C9h Input terminal [6] active state CA-26 R/W
36CBh 36CAh Input terminal [7] active state CA-27 R/W
36CCh 36CBh Input terminal [8] active state CA-28 R/W
36CDh 36CCh Input terminal [9] active state CA-29 R/W
36Ceh 36CDh Input terminal [A] active state CA-30 R/W
36CFh 36CEh Input terminal [B] active state CA-31 R/W
36D9h 36D8h Input terminal [1] response time CA-41 R/W
0 to 400
1(ms)
36Dah 36D9h Input terminal [2] response time CA-42 R/W 1(ms)
36DBh 36Dah Input terminal [3] response time CA-43 R/W 1(ms)
36DCh 36DBh Input terminal [4] response time CA-44 R/W 1(ms)
36DDh 36DCh Input terminal [5] response time CA-45 R/W 1(ms)
36Deh 36DDh Input terminal [6] response time CA-46 R/W 1(ms)
36DFh 36DEh Input terminal [7] response time CA-47 R/W 1(ms)
36E0h 36DFh Input terminal [8] response time CA-48 R/W 1(ms)
36E1h 36E0h Input terminal [9] response time CA-49 R/W 1(ms)
36E2h 36E1h Input terminal [A] response time CA-50 R/W 1(ms)
36E3h 36E2h Input terminal [B] response time CA-51 R/W 1(ms)
36E7h 36E6h
Multistage input determination
time
CA-55 R/W 0 to 2000 1(ms)
36Ech 36EBh
FUP/FDN overwrite target
selection
CA-60 R/W
00: Frequency command
01: PID1
-
36Edh 36ECh FUP/FDN data save enable CA-61 R/W
00: Not save
01: Save
-
To Next Page
