Appendices C Table of Parameters
C - 44
High-function General-purpose Inverter RX2 Series User’s Manual
<List of input terminal functions>
Function No. Abbreviation Function name
000 no Without allocation
001 FW Normal rotation
002 RV Reverse rotation
003 CF1 Multistage speed 1
004 CF2 Multistage speed 2
005 CF3 Multistage speed 3
006 CF4 Multistage speed 4
007 SF1 Multistage speed bit 1
008 SF2 Multistage speed bit 2
009 SF3 Multistage speed bit 3
010 SF4 Multistage speed bit 4
011 SF5 Multistage speed bit 5
012 SF6 Multistage speed bit 6
013 SF7 Multistage speed bit 7
014 ADD Addition of frequency
015 SCHG Switching of command
016 STA 3-wire starting up
017 STP 3-wire stopping
018 F/R 3-wire normal and reverse
019 AHD Retention of analog command
020 FUP Acceleration through remote operation
021 FDN Deceleration through remote operation
022 UDC Clearing of remote operation data
023 F-OP Forced switching of command
024 SET Second control
028 RS Reset
029 JG Jogging
030 DB Braking with external direct current
031 2CH 2-step acceleration/deceleration
032 FRS Free-run stop
033 EXT External abnormality
034 USP Prevention of power restoration restarting
035 CS Commercial switch
036 SFT Soft-lock
037 BOK Brake check
038 OLR Switching of overload limit
039 KHC Clearing of integrated input power
040 OKHC Clearing of integrated output power
041 PID PID1 disabled
042 PIDC Resetting of PID1 integration
043 PID2 PID2 disabled
044 PIDC2 Resetting of PID2 integration
045 PID3 PID3 disabled
046 PIDC3 Resetting of PID3 integration
047 PID4 PID4 disabled
048 PIDC4 Resetting of PID4 integration
051 SVC1 PID1 multistage target value 1
052 SVC2 PID1 multistage target value 2
053 SVC3 PID1 multistage target value 3
054 SVC4 PID1 multistage target value 4
055 PRO Switching of PID gain
056 PIO1 Switching of PID output
