C - 45
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
057 PIO2 Switching of PID output 2
058 SLEP Satisfaction of SLEEP condition
059 WAKE Satisfaction of WAKE condition
060 TL Validation of torque limit
061 TRQ1 Torque limit switchover 1
062 TRQ2 Torque limit switchover 2
063 PPI PPI control switch
064 CAS Control gain switch
065 SON Servo ON
066 FOC Auxiliary excitation
067 ATR Validation of torque control
068 TBS Validation of torque bias
069 ORT Orientation
071 LAC Cancellation of LAD
072 PCLR Clearing of positional deviation
073 STAT
Permission to inputting of Pulse string position com-
mand
074 PUP Addition of positional bias
075 PDN Subtraction of positional bias
076 CP1 Positional command selection 1
077 CP2 Positional command selection 2
078 CP3 Positional command selection 3
079 CP4 Positional command selection 4
080 ORL Origin limit signal
081 ORG Return-to-origin start up signal
082 FOT Stopping of normal rotation driving
083 ROT Stopping of reverse rotation driving
084 SPD Switching of speed position
085 PSET Presetting of positional data
086 MI1 General purpose input 1
087 MI2 General purpose input 2
088 MI3 General purpose input 3
089 MI4 General purpose input 4
090 MI5 General purpose input 5
091 MI6 General purpose input 6
092 MI7 General purpose input 7
093 MI8 General purpose input 8
094 MI9 General purpose input 9
095 MI10 General purpose input 10
096 MI11 General purpose input 11
097 PCC Clearing of pulse counter
098 ECOM Starting up of EzCOM
099 PRG Starting of EzSQ program
100 HLD Stopping of acceleration/deceleration
101 REN Operation permission signal
102 DISP Fixation of display
103 PLA Pulse string input A
104 PLB Pulse string input B
105 EMF Emergency forced operation
107 COK Contactor check signal
109 PLZ Pulse string input Z
110 TCH Teaching signal
Function No. Abbreviation Function name
To Next Page
