Omron RX2 Series User Manual

6 Basic Parameter Settings
6 - 34
High-function General-purpose Inverter RX2 Series User’s Manual
Frequency command is given via DriveProgramming.
A frequency command can be given through the DriveProgramming when Set-Freq command is used
in the program for DriveProgramming.
Precautions for Correct Use
• A program created on PC needs to be downloaded from the PC to the inverter.
• Downloaded program begins working when the program action of the DriveProgramming
function is enabled.
• For the details, see the instruction manual of DriveProgramming SBCE-440.
 Parameter
Frequency command is given with PID control.
To use the PID control for motor control, PID arithmetic is set in the frequency command selection after
the PID function is set.
Precautions for Correct Use
To give a command from the PID control, parameters of the PID control function need to be set.
For details, see 8-1 PID Control on page 8-4.
 Parameter
6-4-6 Case where Command Is Given through DriveProgramming
Item Parameters Data Description
Default
data
Main speed input
source selection,
1st-motor
[AA101] 14
Frequency command from the program function
is enabled.
01
*1
*1. Default data when default data selection (UB-02) is set to 01.
EzSQ function enable [UE-02]
00 Actions of the downloaded programs disabled.
01
01
The program starts when [PRG] terminal is
made ON.
02
The program starts after the setting or power
activation.
6-4-7 Case where Command Is Given with PID Control
Item Parameters Data Description
Default
data
Main speed input
source selection,
1st-motor
[AA101] 15 An arithmetic result of the PID control is output.
01
*1
*1. Default data when default data selection (UB-02) is set to 01.
