9 - 71
9 Communications Functions
High-function General-purpose Inverter RX2 Series User’s Manual
9-5 Modbus Communication Register Number List
9
9-5-5 Group b Register List
5AAAh 33A9h
Electronic thermal level set-
ting, 2nd-motor
bC210 R/W Same as bb110 0.1(A)
5AABh 5AAAh
Electronic thermal character-
istic selection, 2nd-motor
bC211 R/W Same as bb111 -
5AACh 5AABh
Electronic thermal Subtraction
function enable, 2nd-motor
bC212 R/W Same as bC112 -
5AADh 5AACh
Electronic thermal Subtraction
time, 2nd-motor
bC213 R/W Same as bC113 1(s)
5AB4h 5AB3h
Free electronic thermal fre-
quency-1, 2nd-motor
bC220 R/W 0.00 to [bC222] (Hz) 0.01(Hz)
5AB5h 5AB4h
Free electronic thermal cur-
rent-1, 2nd-motor
bC221 R/W Same as bC121 0.1(A)
5AB6h 5AB5h
Free electronic thermal fre-
quency-2, 2nd-motor
bC222 R/W [bC220] to [bC224] (Hz) 0.01(Hz)
5AB7h 5AB6h
Free electronic thermal cur-
rent-2, 2nd-motor
bC223 R/W Same as bC123 0.1(A)
5AB8h 5AB7h
Free electronic thermal fre-
quency-3, 2nd-motor
bC224 R/W [bC222] to 590.00 (Hz) 0.01(Hz)
5AB9h 5AB8h
Free electronic thermal cur-
rent-3, 2nd-motor
bC225 R/W Same as bC125 0.1(A)
*1. On the parameter about the current and the voltage, the figures and the units to be handled vary in the setting path.
1) Operator or CX-Drive: 0.1 A or 0.1 V (When CX-Drive is operated, set [CF-11] Resister data selection to 00 (A, V).
When the data of [CF-11] Resister data selection is not set to 00 (A, V), it is not set or displayed correctly.)
2) Modbus: The current and the voltage vary, depending on the setting of Resister data selection [CF-11].
When [CF-11] Resister data selection is set to 00 (A, V), 0.1 A, 0.1 V
When [CF-11] Resister data selection is set to 01 (%), 0.01% (Rated ratio)
3) Drive programming: 0.01% (Rated ratio)
*2. Minimum resistance values vary in inverter model.
*3. 3G3RX2-B4750 to 3G3RX2-B413K shall be as follows.
[Ub-03]=02: 0.5 to 10.0(kHz)
[Ub-03]=00 or 01: 0.5 to 8.0(kHz)
*4. The feedback input to input terminals A and B and the feedback input to option cassette RX2-PG are necessary.
Register
No.
Modbus
register
spec. No.
Function name
Parame-
ter No.
R/W Monitor or setting data
Resolution
