A - 11
Appendices A Technical Information
High-function General-purpose Inverter RX2 Series User’s Manual
A-2 Parameter Comparison
A
d102 DC voltage monitor dA-40
d103 BRD load factor monitor dA-41
d104 BRD thermal load factor monitor dA-42
F001 Output frequency setting FA-01
F002 First acceleration time setting AC120
F202 Second acceleration time setting AC220
F302 Third acceleration time setting Abolition of third control
F003 First deceleration time setting AC122
F203 Second deceleration time setting AC222
F303 Third deceleration time setting Abolition of third control
F004 Operation direction selection AA-12
A001 Frequency command selection AA101
Addition of individual settings for sec-
ond control
A002 Operation command selection AA111
A003 First base frequency Hb104/Hd104 Hb104: IM, Hd104: SM(PMM)
A203 Second base frequency Hb204/Hd204 Hb204: IM, Hd204: SM(PMM)
A303 Third base frequency Abolition of third control
A004 First maximum frequency Hb105/Hd105 Hb105: IM, Hd105: SM(PMM)
A204 Second maximum frequency Hb205/Hd205 Hb205: IM, Hd205: SM(PMM)
A304 Third maximum frequency Abolition of third control
A005 AT terminal selection
This function is substituted by the set-
ting of AA101/AA102 and SCHG
(input terminal 015)
A006 O2 selection
This function is substituted by the set-
ting of Cb-22
A011 0 start Cb-03 For Ai1
A012 0 end Cb-04 For Ai1
A013 0 start ratio Cb-05 For Ai1
A014 0 end ratio Cb-06 For Ai1
A015 0 start selection Cb-07 For Ai1
A016 Analog input filter Cb-01 For Ai1 (Ai2: Cb-11, Ai3: Cb-21)
A017 Simplified sequence function selection UE-02
A019 Multistep speed selection Ab-03
A020 0th speed of the 1st multi-step speed Ab110
A220 0th speed of the 2nd multi-step speed Ab210
A320 0th speed of the 3rd multi-step speed Abolition of third control
A021 1st speed of the multi-step speed Ab-11
A022 2nd speed of the multi-step speed Ab-12
A023 3rd speed of the multi-step speed Ab-13
A024 4th speed of the multi-step speed Ab-14
A025 5th speed of the multi-step speed Ab-15
A026 6th speed of the multi-step speed Ab-16
A027 7th speed of the multi-step speed Ab-17
A028 8th speed of the multi-step speed Ab-18
A029 9th speed of the multi-step speed Ab-19
A030 10th speed of the multi-step speed Ab-20
A031 11th speed of the multi-step speed Ab-21
A032 12th speed of the multi-step speed Ab-22
A033 13th speed of the multi-step speed Ab-23
A034 14th speed of the multi-step speed Ab-24
A035 15th speed of the multi-step speed Ab-25
A038 Jogging frequency AG-20
3G3RX-series V1 3G3RX2-series
Remarks
Display
code
Function name New code
To Next Page
