Appendices A Technical Information
A - 12
High-function General-purpose Inverter RX2 Series User’s Manual
A039 Jogging selection AG-21
A041 First torque boost selection AA121
When A041 is set to 01, select 03:
automatic boost for AA121.
A241 Second torque boost selection AA221
When A241 is set to 01, select 03:
automatic boost for AA221.
A042 First manual torque boost volume Hb141
* Re-confirmation is required for set-
ting.
A242 Second manual torque boost volume Hb241
* Re-confirmation is required for set-
ting.
A342 Third manual torque boost volume Abolition of third control
A043 First manual torque boost break point Hb142
* Re-confirmation is required for set-
ting.
A243 Second manual torque boost break point Hb242
* Re-confirmation is required for set-
ting.
A343 Third manual torque boost break point Abolition of third control
A044 First control mode AA121
* Re-confirmation is required for set-
ting.
A244 Second control mode AA221
* Re-confirmation is required for set-
ting.
A344 Third control mode Abolition of third control
A045 Output voltage gain Hb180
Addition of individual settings for sec-
ond control
A046
First voltage compensation gain for auto-
matic torque boost
HC101
A246
Second voltage compensation gain for
automatic torque boost
HC201
A047
First slip compensation gain for automatic
torque boost
HC102
A247
Second slip compensation gain for auto-
matic torque boost
HC202
A051 DC braking selection AF101
Addition of individual settings for sec-
ond control
A052 DC braking frequency AF103
Addition of individual settings for sec-
ond control
A053 DC braking delay time AF104
Addition of individual settings for sec-
ond control
A054 DC braking force AF105
Addition of individual settings for sec-
ond control
A055 DC braking time AF106
Addition of individual settings for sec-
ond control
A056 DC braking edge/level selection AF107
Addition of individual settings for sec-
ond control
A057 DC braking force at the start AF108
Addition of individual settings for sec-
ond control
A058 DC braking time at the start AF109
Addition of individual settings for sec-
ond control
A059 DC braking carrier frequency Integrated into bb101
A061 First frequency upper limiter bA102
A261 Second frequency upper limiter bA202
A062 First frequency lower limiter bA103
A262 Second frequency lower limiter bA203
A063 Jump frequency 1 AG101
Addition of individual settings for sec-
ond control
3G3RX-series V1 3G3RX2-series
Remarks
Display
code
Function name New code
