Omron RX2 Series User Manual

8 Applied Settings
8 - 174
High-function General-purpose Inverter RX2 Series User’s Manual
 Output Terminal Selections
Function No. Abbreviation Function name Page
000 no Without allocation -
001 RUN During operation P. 8-140
002 FA1 When the constant speed is attained P. 8-144
003 FA2 Equal to or above the set frequency P. 8-145
004 FA3 Set frequency only P. 8-146
005 FA4 Equal to or above the set frequency 2 P. 8-145
006 FA5 Set frequency only 2 P. 8-146
007 IRDY Operation ready completion P. 8-143
008 FWR During normal rotation operation P. 8-141
009 RVR During reverse rotation operation P. 8-141
010 FREF Frequency command panel P. 6-26
011 REF Operation command panel P. 6-26
012 SETM Second control under selection P. 8-80
016 OPO Optional output P. 8-63
017 AL Alarm signal P. 8-123
018 MJA Severe failure signal P. 8-125
019 OTQ Excessive torque P. 7-51
020 IP During instantaneous power failure P. 8-131
021 UV Under insufficient voltage P. 8-132
022 TRQ During torque limitation P. 7-48
023 IPS During power failure deceleration P. 8-63
024 RNT RUN time elapsed P. 8-137
025 ONT Power supply ON time elapsed P. 8-138
026 THM Electronic thermal warning (motor) P. 8-133
027 THC Electronic thermal warning (inverter) P. 8-134
029 WAC Capacitor life advance notice P. 8-136
030 WAF Fan life advance notice P. 8-136
031 FR Operation command signal P. 8-142
032 OHF Cooling fin heating advance notice P. 8-135
033 LOC Low current signal P. 8-129
034 LOC2 Low current signal 2 P. 8-129
035 OL Overload advance notice P. 8-127
036 OL2 Overload advance notice 2 P. 8-127
037 BRK Brake release P. 8-85
038 BER Brake abnormality P. 8-85
039 CON Contactor control P. 8-91
040 ZS 0 Hz detection signal P. 8-147
041 DSE Excessive speed deviation P. 8-78
042 PDD Excessive positional deviation P. 8-104
043 POK Positioning completed P. 8-108
044 PCMP Pulse count compare-match P. 8-167
045 OD PID excessive deviation P. 8-33
046 FBV PID feedback comparison P. 8-34
047 OD2 PID2 excessive deviation P. 8-33
048 FBV2 PID2 feedback comparison P. 8-34
049 NDc Communication disconnection P. 9-2
050 Ai1Dc Analog disconnection Ai1 P. 8-148
051 Ai2Dc Analog disconnection Ai2 P. 8-148
052 Ai3Dc Analog disconnection Ai3 P. 8-148
056 WCAi1 Window comparator Ai1 P. 8-148
057 WCAi2 Window comparator Ai2 P. 8-148
058 WCAi3 Window comparator Ai3 P. 8-148
