Omron RX2 Series User Manual

9 Communications Functions
9 - 24
High-function General-purpose Inverter RX2 Series User’s Manual
272Ch 272Bh
Pulse counter monitor
dA-28
(HIGH)
R
0 to 2147483647 1(pls)
272Dh 272Ch
dA-29
(LOW)
R
272Eh 272Dh Input power monitor dA-30 R
0 to 60000 (to 132kW)
0 to 20000 (160 kW to)
0.01(kWh)
0.1(kWh)
2730h 273Fh
Integrated input power moni-
tor
dA-32
(HIGH)
R
0 to 10000000 0.1(kWh)
2731h 2730h
dA-33
(LOW)
R
2732h 2731h Output power monitor dA-34 R
0 to 60000 (to 132 kW)
0 to 20000 (160 kW to)
0.01(kWh)
0.1(kWh)
2734h 2733h
Integrated output power
monitor
dA-36
(HIGH)
R
0 to 10000000 0.1(kWh)
2735h 2734h
dA-37
(LOW)
R
2736h 2735h Motor temperature monitor dA-38 R -200 to 2000 0.1(°C)
2738h 2737h DC voltage monitor dA-40 R 0 to 10000 0.1(Vdc)
2739h 2738h BRD load factor monitor dA-41 R 0 to 10000 0.01(%)
273Ah 2739h
Electronic thermal duty ratio
monitor MTR
dA-42 R 0 to 10000 0.01(%)
273Bh 273Ah
Electronic thermal duty ratio
monitor CTL
dA-43 R 0 to 10000 0.01(%)
273Dh 273Ch
Integrated output power
monitor
dA-45 R
00: no input
01: P-1A
02: P-2A
03: P-1b
04: P-2b
05: P-1C
06: P-2C
07: STO
-
2742h 2741h
Terminal block option
mounted state
dA-50 R 00:STD-TM1 (fixed value) -
2743h 2742h Input terminal monitor dA-51 R
LLLLLLLLLLL to
HHHHHHHHHHH [L:OFF/H:ON]
[Left side] (terminal B)
(terminal A) (terminal 9) -
(termianl1) [Right side]
1
2746h 2725h Output terminal monitor dA-54 R
LLLLLLL-HHHHHHH
[L:OFF/H:ON]
[Left side] (terminal AL)
(terminal 16C) (terminal 15) -
(terminal 11) [Right side]
1
274Ch 274Bh Analog I/O selection monitor dA-60 R
AAAAAAAA- VVVVVVVV
[A: current/V: voltage]
[Left side] (Reserved)(Reserved)
(Reserved) (terminal Ai3 (Ii3/Vi3))
(terminal Ao2) (terminal Ao1)
(terminal Ai2) (terminal Ai1)
[Right side]
1
274Dh 274Ch Analog input [Ai1] monitor dA-61 R 0 to 10000 0.01(%)
274Eh 274Dh Analog input [Ai2] monitor dA-62 R 0 to 10000 0.01(%)
274Fh 274Eh Analog input [Ai3] monitor dA-63 R -10000 to 10000 0.01(%)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
