9 - 25
9 Communications Functions
High-function General-purpose Inverter RX2 Series User’s Manual
9-5 Modbus Communication Register Number List
9
9-5-2 Group d Register List
2756h 2755h
Pulse string input monitor
main body
dA-70 R -10000 to 10000 0.01(%)
2757h 2756h
Pulse string input monitor
option
dA-71 R -10000 to 10000 0.01(%)
2761h 2760h Option slot 1 mounted state dA-81 R 00: None -
2762h 2761h Option slot 2 mounted state dA-82 R
00: None
33: RX2-PG
-
2763h 2762h Option slot 3 mounted state dA-83 R 00: None -
2775h 2774h Program download monitor db-01 R
00: Without a program
01: With a program
-
2776h 2775h Program No. monitor db-02 R 0 to 9999 1
2777h 2776h Program counter (Task-1) db-03 R 1 to 1024 1
2778h 2777h Program counter (Task-2) db-04 R 1 to 1024 1
2779h 2778h Program counter (Task-3) db-05 R 1 to 1024 1
277Ah 2779h Program counter (Task-4) db-06 R 1 to 1024 1
277Bh 277Ah Program counter (Task-5) db-07 R 1 to 1024 1
277Ch 277Bh
User monitor 0
db-08
(HIGH)
R
-2147483647 to 2147483647 1
277Dh 277Ch
db-09
(LOW)
R
277Eh 277Dh
User monitor 1
db-10
(HIGH)
R
-2147483647 to 2147483647 1
277Fh 277Eh
db-11
(LOW)
R
2780h 277Fh
User monitor 2
db-12
(HIGH)
R
-2147483647 to 2147483647 1
2781h 2780h
db-13
(LOW)
R
2782h 2781h
User monitor 3
db-14
(HIGH)
R
-2147483647 to 2147483647 1
2783h 2782h
db-15
(LOW)
R
2784h 2783h
User monitor 4
db-16
(HIGH)
R
-2147483647 to 2147483647 1
2785h 2784h
db-17
(LOW)
R
2786h 2785h Analog output monitor YA0 db-18 R 0 to 10000 0.01(%)
2787h 2786h Analog output monitor YA1 db-19 R 0 to 10000 0.01(%)
2788h 2787h Analog output monitor YA2 db-20 R 0 to 10000 0.01(%)
2792h 2791h
PID1 feedback data 1 moni-
tor
db-30
(HIGH)
R
-10000 to 10000
*1
Unit differs
depending
on setting
[AH-03]
[AH-06].
2793h 2792h
db-31
(LOW)
R
2794h 2793h
PID1 feedback data 2 moni-
tor
db-32
(HIGH)
R
-10000 to 10000
*1
Unit differs
depending
on setting
[AH-03]
[AH-06].
2795h 2794h
db-33
(LOW)
R
2796h 2795h
PID1 feedback data 3 moni-
tor
db-34
(HIGH)
R
-10000 to 10000
*1
Unit differs
depending
on setting
[AH-03]
[AH-06].
2797h 2796h
db-35
(LOW)
R
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
