2798h 2797h
PID2 feedback data monitor
db-36
(HIGH)
R
-10000 to 10000
*2
Unit differs
depending
on setting
[AJ-03]
[AJ-06].
2799h 2798h
db-37
(LOW)
R
279Ah 2799h
PID3 feedback data monitor
db-38
(HIGH)
R
-10000 to 10000
*3
Unit differs
depending
on setting
[AJ-23]
[AJ-26].
279Bh 279Ah
db-39
(LOW)
R
279Ch 279Bh
PID4 feedback data monitor
db-40
(HIGH)
R
-10000 to 10000
*4
Unit differs
depending
on setting
[AJ-43]
[AJ-46].
279Dh 279Ch
db-41
(LOW)
R
279Eh 279Dh
PID1 target value monitor
after calculation
db-42
(HIGH)
R
-10000 to 10000
*1
Unit differs
depending
on setting
[AH-03]
[AH-06].
279Fh 279Eh
db-43
(LOW)
R
27A0h 279Fh
PID1 feedback data
db-44
(HIGH)
R
-10000 to 10000
*1
Unit differs
depending
on setting
[AH-03]
[AH-06].
27A1h 27A0h
db-45
(LOW)
R
27A6h 27A5h PID1 output monitor db-50 R -10000 to 10000 0.01(%)
27A7h 27A6h PID1 deviation monitor db-51 R -20000 to 20000 0.01(%)
27A8h 27A7h PID1 deviation 1 monitor db-52 R -20000 to 20000 0.01(%)
27A9h 27A8h PID1 deviation 2 monitor db-53 R -20000 to 20000 0.01(%)
27AAh 27A9h PID1 deviation 3 monitor db-54 R -20000 to 20000 0.01(%)
27ABh 27AAh PID2 output monitor db-55 R -10000 to 10000 0.01(%)
27ACh 27ABh PID2 deviation monitor db-56 R -20000 to 20000 0.01(%)
27ADh 27ACh PID3 output monitor db-57 R -10000 to 10000 0.01(%)
27AEh 27ADh PID3 deviation monitor db-58 R -20000 to 20000 0.01(%)
27AFh 27AEh PID4 output monitor db-59 R -10000 to 10000 0.01(%)
27B0h 27AFh PID4 deviation monitor db-60 R -20000 to 20000 0.01(%)
27B1h 27B0h PID current P gain monitor db-61 R 0 to 1000 0.1(%)
27B2h 27B1h PID current I gain monitor db-62 R 0 to 36000 0.1(s)
27B3h 27B2h PID current D gain monitor db-63 R 0 to 10000 0.01(s)
27B4h 27B3h PID feed-forward monitor db-64 R 0 to 10000 0.01(%)
27D9h 27D8h
Inverter load type selection
monitor
dC-01 R
00: very low duty
01: low duty
02: normal duty
-
27DAh 27D9h Rated current monitor dC-02 R 0 to 65535 0.1(A)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
