Omron RX2 Series User Manual

8 - 179
8 Applied Settings
High-function General-purpose Inverter RX2 Series User’s Manual
8-11 Output Terminal Function
8
8-11-4 Analog Output Terminal Adjustment
Precautions for Correct Use
Data with (±) will be applied to [FM], [Ao1], and [Ao2] when [Cd-12], [Cd-22], and [Cd-32] are
01, respectively. If [Cd-12], [Cd-22], and [Cd-32] are 00, respectively, data with (−) is output as
the absolute value with (+).
dA-18 Output voltage monitor 0 to Rated voltage × 133% (V)
dA-30 Input power monitor
0.00 to Rated power ×
200% (kW)
dA-34 Output power monitor
0.00 to Rated power ×
200% (kW)
Outputting is possible with (±).
Outputting with (+) at powered
state and with (−) at
regenerative state.
dA-38 Motor temperature monitor -20.0 to 200.0(°C)
dA-40 DC voltage monitor
(200 V class)
0.0 to 400.0 (Vdc)
(400 V class)
0.0 to 800.0 (Vdc)
dA-41
Braking circuit (BRD) duty ratio
monitor
0.00 to 100.00(%)
dA-42
Electronic thermal duty ratio
monitor (motor)
0.00 to 100.00(%)
dA-43
Electronic thermal duty ratio
monitor (inverter)
0.00 to 100.00(%)
dA-61 Analog input [Ai1] monitor 0.00 to 100.00(%)
dA-62 Analog input [Ai2] monitor 0.00 to 100.00(%)
dA-63 Analog input [Ai3] monitor -100.00 to 100.00(%) Outputting is possible with (±).
dA-70
Pulse string input monitor
(main body)
-100.00 to 100.00(%) Outputting is possible with (±).
dA-71
Pulse string input monitor
(option)
-100.00 to 100.00(%) Outputting is possible with (±).
*1. To calculate the motor rated torque (100%), use the following formula.
Motor rated torque = 79.58 × Motor capacity × Number of poles/Base frequency
Example: Motor rated torque = 79.58 × 5.5 (kW) × 4 (P)/50 (Hz) ≈ 35 Nm
Code Name
Output scale range
(Corresponding to 0 to 10 V /
0 to 20 mA / 0 to 100%)
Remarks
db-18 Analog output monitor YA1 0.00 to 10000
db-19 Analog output monitor YA2 0.00 to 10000
db-20 Analog output monitor YA3 0.00 to 10000
db-21 Analog output monitor YA4 0.00 to 10000
db-22 Analog output monitor YA5 0.00 to 10000
db-23 Analog output monitor YA6 0.00 to 10000
db-30
PID1 feedback data 1 monitor
-100.00 to 100.00(%)
*1
Outputting is possible with (±).
db-32
PID1 feedback data 2 monitor
-100.00 to 100.00(%)
*1
Outputting is possible with (±).
db-34
PID1 feedback data 3 monitor
-100.00 to 100.00(%)
*1
Outputting is possible with (±).
db-36
PID2 feedback data monitor
-100.00 to 100.00(%)
*2
Outputting is possible with (±).
db-38
PID3 feedback data monitor
-100.00 to 100.00(%)
*3
Outputting is possible with (±).
db-40
PID4 feedback data monitor
-100.00 to 100.00(%)
*4
Outputting is possible with (±).
db-42
PID1 target value monitor
-100.00 to 100.00(%)
*1
Outputting is possible with (±).
Code Name
Output scale range
(Corresponding to 0 to 10 V /
0 to 20 mA / 0 to 100%)
Remarks
