7 - 89
7 Advanced Settings
High-function General-purpose Inverter RX2 Series User’s Manual
7-6 Stop Conditions
7
7-6-2 DC Injection Braking Stop
Edge mode: [AF107]=00 Level mode: [AF107]=01
(Ex.9) (Ex.12)
(Ex.10) (Ex.13)
(Ex.11) (Ex.14)
FW
DB
[AF106]
ON
ON
Output frequency
DC braking
FW
DB
ON
ON
Output frequency
DC braking
FW
DB
[AF106]
ON
ON
Output frequency
DC braking
FW
DB
ON
ON
Output frequency
DC braking
FW
DB
[AF104]
[AF106]
ON
ON
Output frequency
Free-running
DC braking
FW
DB
[AF104]
ON
ON
Output frequency
Free-running
DC braking
