1 Overview
1 - 14
High-function General-purpose Inverter RX2 Series User’s Manual
3G3RX2-A2055/A2075/A2110/A4055/A4075/A4110
Precautions for Correct Use
In case you operate 3G3RX2-A2110 at Low Duty (LD) or Very Low Duty (VLD), the inverter is
subject to the restriction of installing method. As for the details, refer to 2-1-2 Precaution for
Installation on page 2-4.
189
246
4-M6
203
70
1.5
170
2-φ7
149.2
189
22
(78)
189
7
246
(78)
260
210
To Next Page
