2-1-3 Installation Environment
For the calculation of heat radiation from a cabinet, the following table shows the amount of heat gener-
ation (loss) according to the inverter capacity.
Loss according to the Inverter Capacity
Voltage
Loss at 100% load (W)
200V 400V
ND LD VLD ND LD VLD
0.4505365
0.75 65 80 105 62 67 76
1.5 93 118 135 94 98 104
2.2 142 162 197 96 107 134
3.7 225 253 314 145 163 189
5.5 348 365 420 235 260 290
7.5 376 400 520 240 280 306
11 498 625 754 260 306 380
15 742 922 1059 361 444 482
18.5 964 1167 1332 495 601 633
22 1163 1263 1377 687 805 860
30 1317 1536 1698 783 854 920
37 1534 1801 2092 812 880 971
45 1625 1940 2300 1047 1218 1300
55 1878 2669 3046 1130 1488 1592
75 1570 1811 2020
90 2034 2150 2359
110 2219 2397 2557
132 3872 4352 4598
