9 Communications Functions
9 - 86
High-function General-purpose Inverter RX2 Series User’s Manual
61C8h 61C7h
ASR gain mapping I-gain 3,
2nd-motor
HA232 R/W Same as HA132 0.1(%)
61C9h 61C8h
ASR gain mapping P-gain 4,
2nd-motor
HA233 R/W Same as HA133 0.1(%)
61Cah 61C9h
ASR gain mapping I-gain 4,
2nd-motor
HA234 R/W Same as HA134 0.1(%)
620Eh 620Dh
Async. Motor capacity setting,
2nd-motor
Hb202 R/W Same as Hb102 0.01(kW)
620Fh 620Eh
Async. Motor poles setting,
2nd-motor
Hb203 R/W Same as Hb103 1
6210h 620Fh
Async. Motor Base frequency
setting, 2nd-motor
Hb204 R/W
Same as Hb104
0.01(Hz)
6211h 6210h
Async. Motor Maximum fre-
quency setting, 2nd-motor
Hb205 R/W
Same as Hb105
0.01(Hz)
6212h 6211h
Async. Motor rated voltage,
2nd-motor
Hb206 R/W
Same as Hb106
1(V)
6214h 6213h
Async. Motor rated current,
2nd-motor
Hb208
(HIGH)
R/W
Same as Hb108 0.01(A)
6215h 6214h
Hb209
(LOW)
R/W
6216h 6215h
Async. Motor constant R1,
2nd-motor
Hb210
(HIGH)
R/W
Same as Hb110
0.000001
(Ω)
6217h 6216h
Hb211
(LOW)
R/W
6218h 6217h
Async. Motor constant R2,
2nd-motor
Hb212
(HIGH)
R/W
Same as Hb112
0.000001
(Ω)
6219h 6218h
Hb213
(LOW)
R/W
621Ah 6219h
Async. Motor constant L,
2nd-motor
Hb214
(HIGH)
R/W
Same as Hb114
0.000001
(mH)
621Bh 621Ah
Hb215
(LOW)
R/W
621Ch 621Bh
Async. Motor constant Io,
2nd-motor
Hb216
(HIGH)
R/W
Same as Hb116 0.01(A)
621Dh 621Ch
Hb217
(LOW)
R/W
621Eh 621Dh
Async. Motor constant J,
2nd
-mo
tor
Hb218
(HIGH)
R/W
Same as Hb118
0.00001
(kg·m
2)
621Fh 621Eh
Hb219
(LOW)
R/W
622Ah 6229h
Minimum frequency adjust-
ment, 2nd-motor
Hb230 R/W Same as Hb130 0.01(Hz)
622Bh 622Ah
Reduced voltage start time
setting, 2nd-motor
Hb231 R/W Same as Hb131 1(ms)
6234h 6233h
Manual torque boost opera-
tional mode selection,
2nd-motor
Hb240 R/W Same as Hb140 -
6235h 6234h
Manual torque boost value,
2nd-motor
Hb241 R/W Same as Hb141 0.1(%)
6236h 6235h
Manual torque boost Peak
speed, 2nd-motor
Hb242 R/W Same as Hb142 0.1(%)
6239h 6238h Eco drive enable, 2nd-motor Hb245 R/W Same as Hb145 -
623Ah 6239h
Eco drive response adjust-
ment, 2nd-motor
Hb246 R/W Same as Hb146 1(%)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data
Resolution
