Omron RX2 Series - Page 720

11 Options
11 - 22
High-function General-purpose Inverter RX2 Series User’s Manual
8
1 Braking unit and
2 groups of
2 parallel resistor
units are
series-connected
9
1 Braking unit and
2 groups of
3 parallel resistor
units are
series-connected
10
1 Braking unit and
2 groups of
4 parallel resistor
units are
series-connected
11
1 Braking unit and
5 resistor units
connected in paral-
lel
12
1 Braking unit and
6 resistor units
connected in paral-
lel
No. Connection form
P/+
Inverter
PRB
N/–
N
R
R
R
R
Voltage
detection
P/+
Inverter
PRB
N/–
N
R
R
R
R
R
R
Voltage
detection
P/+
Inverter
PRB
Braking unit
(Resistor mounted externally)
N/–
N
RRRR
RRRR
Voltage
detection
P/+
Inverter
PRB
Braking unit
(Resistor mounted externally)
N/–
N
RRRRR
Voltage
detection
P/+
Inverter
PRB
Braking unit
(Resistor mounted externally)
N/–
N
RRRRRR
Voltage
detection
