A-1 Comparison of External Dimensions
A
3G3RX-A2055- V1 → 3G3RX2-A2055
3G3RX-A2075- V1 → 3G3RX2-A2075
3G3RX-A2110- V1 →
3G3RX2-A2110
*1
3G3RX-A4055- V1 → 3G3RX2-A4055
3G3RX-A4075- V1 → 3G3RX2-A4075
3G3RX-A4110- V1 → 3G3RX2-A4110
→
*1. When these series are used with 3G3RX2-A2110(LD)(VLD), the depth dimention gets large. As for the detail, refer to
2-1-2 Precaution for Installation on page 2-4.
3G3RX-series V1 type → 3G3RX2-series
203
82
13.6
2-φ7
169
189
24.5
80
189
7
246
79
260
210
170
203
70
1.5
170
2-φ7
149.2
189
22
(78)
189
7
246
(78)
260
210
