Orolia SecureSync 2400 User Manual

Table 2-6:
Multi I/O Input and Output Options
Pin Location Available Signal Types Web UI Selection
DCLS OUT Pin 6 (signal)
Pin 7 (ground)
1PPS Output PPS_OUT|DCLS_TTL
IRIG Output (Default)
IRIG_OUT|DCLS_TTL
HaveQuick Output HQ_OUT|DCLS_TTL
GPIOOutput GPIO_OUT|DCLS_TTL
DCLS IN Pin 1 (signal)
Pin 2 (ground)
1PPSInput PPS_IN|DCLS_TTL
IRIGInput (Default)
IRIG_IN|DCLS_TTL
HaveQuick Input HQ_IN|DCLS_TTL
RS232 IN Pin 15 (signal)
Pin 10 (ground)
ASCII Time Code Input (Default)
ATC_IN | RS232
RS232 OUT Pin 5 (signal)
Pin 10 (ground)
ASCII Time Code Output (Default)
ATC_OUT | RS232
RS485 (#1) Pin 3 (signal)
Pin 13 (signal)
Pin 8 (ground)
1PPS Output PPS_OUT | RS485
IRIG Output IRIG_OUT | RS485
HaveQuick Output (Default)
HQ_OUT | RS485
ASCII Time Code Output ATC_OUT | RS485
1PPS Input PPS_IN | RS485
IRIG Input IRIG_IN | RS485
HaveQuick Input HQ_IN | RS485
ASCII Time Code Input ATC_IN | RS485
RS485 (#2) Pin 4 (signal)
Pin 14 (signal)
Pin 9 (ground)
1PPS Output PPS_OUT | RS485
IRIG Output IRIG_OUT | RS485
HaveQuick Output HQ_OUT | RS485
ASCII Time Code Output ATC_OUT | RS485
1PPS Input PPS_IN | RS485
IRIG Input IRIG_IN | RS485
HaveQuick Input (Default)
HQ_IN | RS485
ASCII Time Code Input ATC_IN | RS485
IRIGAM Output Pin 11 (signal)
Pin 12 (ground)
IRIG AM Output (Default, non-configurable)
2.18 Configurable Connectors
CHAPTER 2 • SecureSync 2400 User Manual Rev. 2
137
