Orolia SecureSync 2400 User Manual

1.6.3 10 MHz Output
Signal: 10 MHz sine wave
Signal Level: +13 dBm ±2dB into 50 Ω
Harmonics: ˗40 dBc minimum
Spurious: ˗70 dBc minimum TCXO
Connector: BNC female
Signature Control: This configurable feature removes the output signal whenever
a major alarm condition or loss of time synchronization condition is present. The out-
put will be restored once the fault condition is corrected.
Accuracy rating depends on the oscillator selected during the ordering process.
Table 1-7:
10 MHz output — oscillator types and accuracies
Oscillator Type Accuracy
Low-phase noise Rubidium 1x10
-12
typical 24-hour average locked to GPS
1x10
-11
per day (5x10
-11
per month) typical aging unlocked
Rubidium 1x10
-12
typical 24-hour average locked to GPS
1x10
-11
per day (5x10
-11
per month) typical aging unlocked
Low-phase noise OCXO 1x10
-12
typical 24-hour average locked to GPS
2x10
-10
per day typical aging unlocked
OCXO 2x10
-12
typical 24-hour average locked to GPS
1x10
-9
per day typical aging unlocked
TCXO 1x10
-11
typical 24-hour average locked to GPS
1x10
-8
per day typical aging unlocked
Note: Oscillator accuracies are stated as fractional frequency (i.e. the rel-
ative frequency departure of a frequency source), and as such are dimen-
sionless.
See also "Configuring the Oscillator" on page230.
24
CHAPTER 1 • SecureSync 2400 User Manual Rev. 2
