stream to UTC time for use by the System Time. The available choices are:
UTC : Coordinated Universal Time ("temps universel coordonné"), also
referred to as ZULU time
TAI: Temps Atomique International
GPS: The raw GPS time as transmitted by the GNSS satellites (as of 15-Febru-
ary-2021, this is 18 seconds ahead of UTC time).
A local clock can be set up through the Time Management Page; see "Local
Clock(s), DST" on page179. Local timescale allows a Local Clock to apply a
time offset for Time Zone and DST correction.
Offset: Provides the ability to account for STANAG Line (TOD1 and TOD2 inde-
pendently) cable delays or other latencies in the STANAG input. Available Offset
range is –500 to +500ms in 5ns steps.
Stanag TFOM: The Time Figure of Merit for the input.
Under 1PPS Input:
1PPS Offset: Used to account for 1PPS cable delays or other latencies in the 1PPS
input. The available Offset range is –500 to +500ms in 5ns steps.
PPS Edge: Indicates whether the output signal is a rising or falling edge pulse.
PPS Electrical Format: Indicates whether the signal is synchronized to RS-485 or
TTL (supporting up to 10 V levels) signal lines.
5.2.5.5 HAVE QUICK Out [1204-10, -1B]
The HAVE QUICK option cards provide (4) HAVE QUICK outputs for the SecureSync plat-
form.
HAVE QUICK Out, BNC [1204-10]: Specifications
Outputs: (4) HAVE QUICK
Signal Type and Connector: TTL levels (BNC)
Formats Supported:
STANAG 4246 HAVE QUICK I
STANAG 4246 HAVE QUICK II
STANAG 4372 HAVE QUICK IIA
SecureSync 2400 User Manual 433
