For additional information on troubleshooting GNSS reception issues with SecureSync,
please refer to the GNSS Reception Troubleshooting Guide, available here on the Orolia
website.
5.1.6 Troubleshooting – Outputs
If the 1PPS from the DCLSOUTBNC connector and/or the 15-pin multi-I/O connector out-
puts are not present, input power may not be applied. Or SecureSync is not synchronized
to its input references and Signature Control is enabled.
Table 5-2:
Troubleshooting outputs not being present
Web UI Page Current Status Indication Troubleshooting
HOME page Reference
Status Table
One or more
input ref-
erences indic-
ate “Not Valid”
(red)
All available Input References have
been lost. The Reference Status
table on this same page will show
the current status of all inputs
(Green is valid and red is not valid,
or not present). If Signature Control
is enabled in this state, the output
may be disabled.
1. Make sure the Input Reference Pri-
ority table still has the desired inputs
enabled, based on desired priority.
2. Make sure desired input ref-
erences are still connected to the
correct input port of SecureSync.
3. Verify GNSS antenna installation
(if applicable).
Navigate to
INTERFACES/OUTPUTS
page
Select the Out-
puts screen.
Signature Con-
trol will show
"Output Always
Enabled",
"Output
Enabled in Hol-
dover",
"Output Dis-
abled in Hol-
dover" or
"Output Always
Disabled".
1. With "Output Always Enabled"
selected, the selected output will be
present no matter the current syn-
chronization state.2. Any other con-
figured value will cause the
applicable output to be halted if
SecureSync is not fully synchronized
with its input references.
330 SecureSync 2400 User Manual
