In both graphs, to see a legend of the graphical data, and time-specific status data,
click inside the graph, choosing the desired point in time. If necessary, increase the
time resolution by dragging the time sliders. A pop-up window will display the legend
for that graph, and the status information for the selected time.
3.3.3.2 Determining Your GNSS Receiver Model
Note: All SecureSync models are currently shipped with a u-blox M8T
Receiver.
To determine which GNSS receiver model is installed in a SecureSync unit:
1.
Navigate to TOOLS > SYSTEM: Upgrade/Backup.
2.
In the System Configuration panel, locate the line item GNSS Receiver:
GNSS Receiver Models
Orolia strives to equip SecureSync with current technology. Depending on the production
date of your SecureSync unit, one of the following GNSS receiver models will be installed
in your unit (if any):
208
CHAPTER 3 • SecureSync 2400 User Manual Rev. 2
3.3 Managing References
