Orolia SecureSync 2400 User Manual

4.5 Quality Management
4.5.1 System Monitoring
4.5.1.1 Status Monitoring via Front Panel
When you have physical access to the SecureSync front panel, you can obtain a system
status overview. To see specifics on how to operate the front panel, see "Front Panel
Keypad, and Display" on page6
Figure 4-4: Front panel layout
Figure 4-5: Status LED menu buttons
The GNSS Menu provides monitoring of the tracked constellations under the
MONITORINGsubmenu. Toggle between constellations to see a chart of each tracked
satellite.
The INPUTS Menu provides monitoring of the references and the order of their priority
under the MONITORING submenu.
The TIMING Menu provides a discription of the current oscillator state in the
MONITORING submenu.
4.5 Quality Management
CHAPTER 4 • SecureSync 2400 User Manual Rev. 2
279
