Note: If the Format value is changed, the Control Field and Coded Expres-
sion change to the default values for the given Format value. The user can
only change the Control Field field and Coded Expression field to allowed val-
ues for the Format field.
It is recommended that the SecureSync administrator/operator only use this if they do not
know what the IRIG Input Format is, and they wish to identify the signal type, or to determ-
ine if a signal is present.
Local Clock: The incoming IRIG input time information may be provided as local
time, but System Time may be configured as UTC time, so internal computations
need to be performed. With the Timescale field set to “Local”, select the name of a
previously created Local Clock. The Time Zone and DST rules, as configured in the
Local Clock will be applied to the front panel time display.
Offset: Provides the ability to account for IRIG cable delays or other latencies in the
IRIG input. The Offset value is entered and displayed in nanoseconds (ns). The avail-
able Offset range is -500 to +500 ms.
2.20 Configuring Outputs
Depending on the type of output interface, some of its settings may be user-editable. To
access these settings for a given output, choose one of the two methods described below.
For information on disabling and enabling outputs, see "Signature Control" on page161
Note: The illustrations shown below are examples. The windows displayed
in your Web UI may look differently.
2.20.1 How to Configure an Output
To access the user-editable settings of an Output, choose one of these two methods:
Configuring the settings of an output, method 1:
148
CHAPTER 2 • SecureSync 2400 User Manual Rev. 2
2.20 Configuring Outputs
